P.02 / SAMPLING

Samplix.

Autonomous in-tank fish sampling.

A surface drone with onboard sonar quietly traces each pen, classifying size and distribution without disturbing the fish — replacing the dip-net with a daily dataset.

Autonomous SONAR Size analytics Non-invasive
SAMPLIX · SURFACE DRONE
Sampling
Samplix surface drone
How it works

A daily sample, with no net.

Samplix turns sampling into a repeatable, reproducible operation — no manual dipping, no operator-to-operator drift.

01

Surface navigation.

Samplix follows pre-defined or adaptive paths across the pen, holding station gently against drift.

02

SONAR detection.

An onboard transducer scans the water column. Fish targets are detected, segmented and tracked frame-by-frame.

03

Size distribution.

Length and biomass distributions are computed automatically and exported with timestamps and pen IDs.

Samplix underside detail
Underside/ DETAIL

Built for the
water column.

Under the float: a forward-facing sonar dome, a compact electric thruster for station-keeping, and discrete ballast points that hold trim across changing loads — quiet enough not to spook the stock.

  • Sonar dome
    Forward-facing acoustic transducer in a clear sealed housing.
  • Electric thruster
    Low-noise drive for autonomous path holding.
  • Ballast points
    Quick adjustment for the species and the season.
Specifications

Specifications.

Product code
SAMPLIX-SD-01
Platform
Autonomous surface drone
Navigation
GPS + IMU + obstacle avoidance
Sensor
SONAR · 200 kHz
Range
0–18 m water column
Outputs
Size distribution · CV · Pen / time stamped reports
Export
CSV · API
Operation
Daily autonomous run
Next steps

Sample every pen, every day.
